IDX P-Vmicro V-Mount Plate for Imicro Batteries =

Description

IDX P-Vmicro V-Mount Plate for Imicro Batteries with Multipurpose Cheese Plate Kit The P-Vmicro is a V-Mount adapter plate sized to fit Imicro batteries. Equipped with 2x D-Taps and USB-C output. *Screw hole pattern is not standard (see image)* Tech Specs: Output Connectors: (2) D-Tap, (1) USB-C D-Tap Output Voltage: Battery through voltage Maximum D-Tap Output: 80W USB-C: DC 5V / 2.3A max Battery Connector Max Current: 14A Ambient Temperature: -4F~113F (discharge) Dimensions: 2.6(W) x 3.78(H) x 1.1(D) inches Weight: 0.25 lbs approx. Included Accessories: (4x) M3 x 10 Double SEMS screws A-CPmicro The A-CPmicro Cheese Plate is a multi-purpose micro plate to accommodate the P-Vmicro on to rigs, bridge plates, gimbals, etc. Tech Specs Material: 6061 Aluminum / Black anodized Screw Holes (11) 1/4 (8) 1/4 (side) (6) 3/8 with counter bores (4) M4 (4) M3 Clamp Mounting (6) Positions Compatible V-Mount Plates P-Vmicro Dimensions: 3.11(W) x 4.29(H) x 0.71(D) inches Weight: 0.38 lbs approx.
